RUBBER VACUUM BELTFILTER
Typical Applications Gold and silver recovery in cyanide processes Recovery of Manganese Washing of Phosphate rock Tailings washing as final stage after CCD Cement copper Acid Leached Copper and Cobalt Washing of Nitrates Hemi- and Di-hydrate calcium sulphate from phosphoric acid Recovery of alumina from sintered mud Uranium recovery after acid or carbonate leaches Cellulose pulp washing Recovery of brine Soda ash Vanadium and Tungsten recovery Sugar cane mud washing.
VACUUM DISC FILTER
VACUUM DISC FILTER Disk vacuum filter uses vacuum as its filtering power to carry out solid-liquid separation of pulp. Unloading by anti-blowing, variable speed agitating, and automatic centralized lubrication and other advanced technologies make it to be the dehydration equipment with good performance and reliable application. This machine is the new type disk vacuum filter exclusively designed for the dehydration of iron ore concentrate and non-ferrous metal ore. It also applies to coal washing plant, as well as non-metal ores, chemical industry and environmental protection operation. Requirements for dehydrating objects of this machine are as follows: 1.1 Mineral granularity is 100 to 400 meshes. 1.2 Pulp density is 35％~65% (metallic mineral) or 20％~40％ (coal and other lightweight materials). 1.3 Pulp temperature is 10℃~30℃. 1.4 Material is non-corrosive (when corrosive material is treated, it shall be specially designed).
CAKE DISCHARGE
